The JAC CPD10S mini–CPD15S mini is a compact seated three-wheel electric forklift series built for tight warehouse aisles, retail backrooms, production areas and other smooth-floor applications where maneuverability and floor protection matter. Three models provide rated capacities from 2,200 to 3,300 lb while sharing a narrow 36.1 in overall width, 53.1 in turning radius, 118.1 in standard lift height and 24V battery platform.
Its short 42.9 in wheelbase, compact chassis and three-wheel steering layout support stacking, transport, loading and unloading in confined spaces. Automatic speed reduction while cornering adds stability, while polyurethane/solid-rubber tires and a relatively light chassis help reduce floor loading. A standard built-in charger supports flexible charging without a separate external charging station.
Why choose the JAC CPD10S mini–CPD15S mini
- Compact and maneuverable: A 36.1 in overall width and 53.1 in turning radius help the forklift work in restricted spaces.
- Three capacity choices: Select 2,200, 2,800 or 3,300 lb rated capacity without moving to a much larger chassis.
- Floor-friendly design: Polyurethane/solid-rubber tires and relatively low service weight are suited to finished commercial and warehouse floors.
- Seated operator layout: The operator compartment provides a spacious arrangement with controls positioned within easy reach.
- Stable cornering: Automatic speed reduction while turning helps improve stability in tight working areas.
- Flexible charging: A standard onboard charger and 24V battery system support convenient charging.
- Low-maintenance electric platform: Separate drive, lift and steering motors provide dependable electric operation with reduced routine upkeep.
Model and capacity comparison
| Model | Rated capacity | Battery | Service weight | Overall length | Minimum stacking aisle* |
|---|---|---|---|---|---|
| CPD10S mini | 2,200 lb / 1,000 kg | 24V / 300Ah | 4,057 lb / 1,840 kg | 99.6 in / 2,530 mm | 119.6 in / 3,038 mm |
| CPD13S mini | 2,800 lb / 1,300 kg | 24V / 350Ah | 4,519 lb / 2,050 kg | 99.6 in / 2,530 mm | 119.6 in / 3,038 mm |
| CPD15S mini | 3,300 lb / 1,500 kg | 24V / 400Ah | 4,828 lb / 2,190 kg | 97.0 in / 2,465 mm | 117.1 in / 2,975 mm |
*Minimum stacking aisle shown for an 800 × 1,200 mm pallet handled lengthwise.
Shared standard specifications
| Power source | 24V battery electric |
|---|---|
| Operator position | Seated |
| Load center | 19.7 in / 500 mm |
| Wheelbase | 42.9 in / 1,090 mm |
| Overall width | 36.1 in / 917 mm |
| Standard lift height | 118.1 in / 3,000 mm |
| Free lift | 5.3 in / 135 mm |
| Lowered mast height | 78.5 in / 1,995 mm |
| Extended mast height | 155.5 in / 3,949 mm |
| Mast tilt | 2° forward / 5° backward |
| Overhead guard height | 78.0 in / 1,980 mm |
| Turning radius | 53.1 in / 1,348 mm |
| Ground clearance | 3.5 in / 90 mm |
| Standard fork size | 1.4 × 3.9 × 37.4 in / 35 × 100 × 950 mm |
| Tires | Polyurethane / solid rubber |
| Typical operating time | Approximately 5 hours under specified operating conditions |
Travel and electric-drive performance
| Travel speed, loaded / unloaded | 3.9 / 4.5 mph (6.2 / 7.2 km/h) |
|---|---|
| Gradeability, loaded / unloaded | 6% / 10% |
| Lift speed, loaded / unloaded | 5.3 / 8.5 in/s (135 / 215 mm/s) |
| Lowering speed, loaded / unloaded | 9.4 / 8.9 in/s (238 / 225 mm/s) |
| Drive motor | 24V / 2.5 kW |
| Lift motor | 24V / 4.5 kW |
| Steering motor | 24V / 0.2 kW |
Best-fit applications
The CPD10S mini–CPD15S mini series is designed for smooth-floor warehouses, retail stockrooms, production areas, distribution staging, commercial facilities and other operations that need a compact seated forklift for stacking, transporting, loading and unloading in limited space.
Configure your JAC mini electric forklift with HaulPro
HaulPro will help confirm capacity, mast height, lowered mast clearance, fork spread, battery capacity, charger requirements, floor conditions, delivery and financing. Call (845) 935-0040 for current pricing and availability.
